Landsväg, Gravel & CXVectorCreated using Figma

Designed to deliver improved aerodynamics by placing hands closer together and nearer to the riders head to start airflow over the rider sooner. Designed with input from top bike fitters, the shape of the Vuka Alumina Evo is crafted to feel as if the rider is shaking hands with the bar. This is achieved through the use of a multi-radius bend paired with a 20mm inward roll of the bar that can be adjusted to dial in fit and achieve an ideal position.

Made from 2014 series aluminum, the clip is available with an above-bar or below-bar mounting system for achieving an optimized aero position. The clip also has a large armrest for increased comfort. The Vuka Alumina Clip is made with the industry standard 22.2mm clamp diameter for maximum versatility, making it compatible with Vuka Alumina Extensions, the new Vuka Extensions (carbon) as well as most extensions on the market.



With a bar clamp diameter of 31.8mm, the Vuka Alumina Clip also is compatible with the Zipp Vuka Alumina and VukaBull base bars and three Zipp drop bars types, Service CourseService Course SL and the SLC2. It also is compatible with many other base bars and drop bars on the market.

  • Vuka Alumina Ski-Tip for a hand position with long-haul comfort. 185 grams
  • The Vuka Alumina Clip weighs 310 grams for the above-bar system (Hög montering).


Extensions and Clip in Top Mount / 1 set

Alu Ski-Tip extensions
Weight 185g
Length 330mm
Shifter fit plug style
Rise 40° or 70mm
Clip Clamp Fit 22.2mm
Clip Clamp Torque 4Nm



Weight
Vuka Alumina Top Mount 310g

Clamping torque
Clip to bar 7Nm
Extension clamp 4Nm
Extension fit 22.2 +0.15 -0.05mm
Stack at pad (adjustability)
Min 37mm per side
Max 110mm per side
Adjustment 73mm per side
Total Adjustment 146mm
Pad Reach
Min behind center 50mm per side
Max in front of center 50mm per side
Adjustment 100mm per side
Total Adjustment 200mm
Reach (extension fore/aft)
Min 0mm per extension
Max 55mm per extension
Adjustment 110mm
Pad Width
Max 90mm
Adjustment 90mm Total
Extension Width on base bar
per side 25mm
Adjustment 50mm Total

Zipp Styre/Clip, Aero Clip/Extensions Vuka Alumina, Ski-tip Alu, Hög montering 22.2

EXTEND YOUR LEAD Zipp developed an extensive line of aluminum aerobar extensions to provide the perfect fit for any rider, regardless of size or riding position. Our Vuka Alumina Extensions comes in the Ski-Tip..
1 602,00 kr

Du är nu med på listan

Lagerstatus: Beställningsvara (Tillfälligt slut hos evalds och webblager)

Artikelnummer:006618020002

Du har väl Webbonus? Bra priser blir superbra...

5% x-tra rabatt på denna vara =

1 522,00 kr
Bli medlem >
