TRAVEL |
130/140/150mm - 26",27.5" , 120/130/140mm - 29" |
WHEELS |
26", 27.5", 29" |
AXLE TO CROWN |
539mm - 27.5"/150mm travel, 548mm - 29"/140mm travel |
WEIGHT |
1736g - 26" , 1780g - 27.5" , 1834g - 29" |
DAMPING |
Motion Control DNA with Dig valve and Rapid Recovery rebound |
AVAILABLE SPRINGS |
Dual Position Air, Solo Air |
ADJUSTMENTS |
Damping: External rebound, low speed compression, 3-position compression (Open/Platform/Lock) ; Travel: Dual Position Air (+ 80g) ; Spring: Air pressure via single schrader valve |
STEERER OPTIONS |
Tapered aluminum |
CROWN |
Forged, hollow 6061 T-6 aluminum |
UPPER TUBES |
32mm tapered wall aluminum, Fast Black |
LOWERS |
Magnesium, disc only |
OPTIONS |
Travel, Spring, Axle, Colors |
RECOMMENDED REAR SHOCK |
Monarch |
MAXIMUM ROTOR SIZE |
200mm |
COLOR OPTIONS |
Black, Diffusion Black, White |
REMOTES |
N/A |
OTHER |
Upgrade over RLT: Additional adjustment capability and improved damping performance, *Weight based on 265mm steerer |
